Description
• Full Nursing height
• Compatible with specialist mattress systems
• Bed rails compliant for foam and dynamic mattresses
• No trailing wires
• Back rest/elevation
• Knee break
• Compatible with specialist mattress systems
• Bed rails compliant for foam and dynamic mattresses
• No trailing wires
• Back rest/elevation
• Knee break
Detailed Specification
Specifications:
• Castor Wheels: 4 x 75mm with brake
• Adjustable height range: 250mm to 760mm
• Back rest positioning: 75°
• Leg rest positioning: 35°
• Max Self Help Pole Lifting Load: 75kg
• Side rail height above the mattress platform (without the mattress) at the highest height: 425mm
• Side rail height above the mattress platform (without the mattress) at the lowest height: 75mm
• Safe working load:180kg
• Maximum patient weight (using a typical mattress of 10kg): 170kg
• Mattress Platform Dimensions: 1050mm W × 2000mm L
• Castor Wheels: 4 x 75mm with brake
• Adjustable height range: 250mm to 760mm
• Back rest positioning: 75°
• Leg rest positioning: 35°
• Max Self Help Pole Lifting Load: 75kg
• Side rail height above the mattress platform (without the mattress) at the highest height: 425mm
• Side rail height above the mattress platform (without the mattress) at the lowest height: 75mm
• Safe working load:180kg
• Maximum patient weight (using a typical mattress of 10kg): 170kg
• Mattress Platform Dimensions: 1050mm W × 2000mm L
Downloads and More
Preventive Maintenance
IEC 60601 | 12 Month Inspection
